Model No.: FTTH Patch Cord
Brand: OEM
Product Name: FTTH Drop Fiber Optic Cable
Outer Sheath: PVC/LSZH
Cores Number: 1-12cores
Fiber Type: G652D, G655,G657A,G657B
Armored Type: Steel Tape or Aluminium Tape
Central Member: FRP
Strength Member: FRP
Keyword: FTTH Duct Cable
Certification: ISO,SGS
OEM: YES
| Selling Units: | Kilometer |
| Package Type: | wooden roll |
| Picture Example: |
|
The file is encrypted. Please fill in the following information to continue accessing it
A fiber optic patch cord is a fiber optic cable capped at either end with connectors that allow it to be rapidly and conveniently connected to CATV, an optical switch or other telecommunication equipment. Its thick layer of protection is used to connect the optical transmitter, receiver, and the terminal box. This is known as" interconnect-style cabling".
Product Name:FTTH Patch Cord,fiber cable patch cord,pre connectorized,pre connectorized drop cable,pre connectorized,pre terminated fiber optic cable
Specification of Fiber Connectors Lc Sc St
| Item | Unit | FC,SC,ST/PC | FC,SC,ST/UPC | FC,SC,ST/APC |
| Insertion Loss | dB | ≤0.20 | ≤0.20 | ≤0.30 |
| Repeatability | dB | ≤0.10 | ||
| Exchangeability | dB | ≤0.20 | ||
| Return Loss | dB | ≥45(SM) | ≥50(SM) | ≥60(SM) |
| Fiber Type | Corning SMF-28TM, 9/125um (SM), 50/125um or 62.5/125um(MM) | |||
| Operating Temperature | °C | -40~+70 | ||
| Storage Temperature | °C | -40~+70 | ||
| Durability | time | >1000 times | ||
Feasure of fiber optic patch cord
1) Low insertion loss high return loss
2)Excellent mechanical endurance
3)High credibility and stability
4)Good in repeatability and exchangeability
Application of fiber optic patch cord
1) Fiber optic communication networks
2) Optical access network
3) Data processing networks
4)Premise installations
Packaging: wooden roll
Productivity: 15000 kilometer per month
Transportation: Ocean,Land,Air,Express
Place of Origin: China
Supply Ability: 15000 kilometer per month
Certificate: ISO,SGS
HS Code: 8544700000
Port: Shenzhen,Guangzhou,Shanghai
Payment Type: L/C,T/T,D/P,Paypal,D/A,others
Incoterm: FOB,CFR,CIF,EXW,FAS,DDP,DDU,Express Delivery
