SC sm single mode fiber patch cord cables

SC sm single mode fiber patch cord cables

Payment Type:	L/C,T/T,D/P,Paypal,Cash
Incoterm:	FOB,CFR,CIF,EXW,FAS,DDP,DDU,Express Delivery
Transportation:	Ocean,Land,Air,Express
Port:	Shenzhen,Guangzhou,Shanghai

Contact Now

Product Attributes
Packaging & Delivery
Product Description
Supply Ability & Additional Information
Other information

Product Attributes

Model No.: SC-SC

Brand: OEM

Brand Name: OEM or neutral

Network: 3G,4G

Product Name: Fiber Patch Cord

Fiber Type: G652D,G657A,OM1,OM2,OM3,OM4

Cable Diameter: 0.9mm/2.0mm/3.0mm

Connector Type: SC,FC,LC,ST

Outer Jacket: PVC/LSZH/OFNP

Fiber Cores: Simplex or Duplex

Certification: RoHS/ISO9001

Leading Time: 5-7 Working Days

Packaging & Delivery

Selling Units:	Piece/Pieces
Package Type:	Normal neutral packaging and neutral labels without branding and logo
Picture Example:

The file is encrypted. Please fill in the following information to continue accessing it

Product Description

SC UPC APC single mode fiber patch cord cables

Description:

Armored patch cord can be laid in all kinds of environmental extremes. It is used without protection tube which saves space and is quite convenient for maintenance. Also it has the construction including stainless steel tube which protects optical fiber and provide better security for the whole system.

SC SC fiber optic patch cords are used for terminating jumpers from equipment to fibre optic cabling links.With a thicker protective layer, SC-SC fibre optic patch cords are generally used for the connection between the optical terminal and the termination box.

Sc Sc single mode patch cord are mainly divided into two categories.

1. Single-mode fiber: SC-SC single-mode fiber jumper is generally indicated in yellow, with blue connectors and protective sleeves; the transmission distance is longer.

2. Multi-mode Fiber: SC-SC multi-mode fiber optic patch cords are generally orange, some are gray, with beige or black connectors and protective sleeves; the transmission distance is shorter.

Product Name:single mode fiber patch cord,sm fiber patch cables,sc fiber patch cable,single mode patch cables,fiber patch,fiber patch cord type,patch cord price,sc patch cord,optical patch cord,sc to sc patch cord,sc apc patch cord,single mode fiber patch cable,fiber cable patch,sc to lc fiber patch cable,lc fiber patch cord,patch fiber optic,sm fiber patch cord,fc fiber patch cord,5m patch cable,corning fiber patch cords,simplex fiber patch cord,duplex fiber optic patch cable,multimode fiber patch cord,patch lc sc,fiber patch cord types,optical patch cord types,optical fiber patch cord type,sc apc patch cord,st to sc patch cord

Performance Specification:

Connector Type	FC, SC, LC, ST, MU, MTRJ
Fiber Type	SM(G.652D/G.657A)			MM(OM1/OM2/OM3/OM4)
Ferrule End-face	PC	UPC	APC	UPC
Insertion Loss	≤0.2dB	≤0.2dB	≤0.3dB	≤0.3bB
Return Loss	≥50dB	≥55dB	≥60dB	≥35dB
Exchangeability	≤0.2dB
Repeatability	≤ 0.1dB(1000 times)
Durability	> 1000 times
Operating Temperature	-40°C ~ +85°C

fiber optic cable Performance Specification:

Fiber type	Min. Bandwidth	Distance	Attenuation
62.5/125	850/1300nm 200/500 MHz/Km	@100Mbps 2km @1Gig 220m	850/1300nm 3.0/1.0dB/km
50/125	850/1300nm 500/500 MHz/Km	@100Mbps 2km @1Gig 500m	850/1300nm 3.0/1.0dB/km
50/125 10Gig Optimized	850/1300nm 2000/500 MHz/Km	@100Gig Varies by VCSEL typical 300m 2850nm	850/1300nm 3.0/1.0dB/km
9/125	1310/1550nm Approx 100 Terahertz	Up to 100km Varies by transceiver	1310/1550nm 0.4/0.3dB/km

Specification:

Item	Single mode
Ferrule End-face	PC	UPC	APC
Insert attenuation	≤0.3dB	≤0.3dB	≤0.3dB
Return loss	≥45dB	≥50dB	≥55dB
Repeatability	≤0.1dB	≤0.1dB	≤0.1dB
Operation temperature	-20°C~+70°C(PVC)/-40°C~+90°C(LSZH/PU)
Outer diameter	1.6mm,2.0mm,3,0mm

SC to SC multimode fiber patch cable product features

1、Three types of end-grinding: PC, UPC, APC
2、Number of cores: single-core, multi-core
3、connectors: LC (small square port), SC (large square port), FC (round port), ST (bayonet), etc.
4、Configuration: SC-SC, SC-LC, SC-ST, SC-FC, etc.
5、Mechanical durability 500 times
6、outer sheath material has PVC, LSZH and other materials to choose

SC SC Fiber Optic Patch Cord applications.
1、Fiber optic communication system.
2、Fiber optic access network.
3、Fiber optic data transmission.
4、Fiber optic CATV.
5、Local Area Network (LAN).
6、test equipment.
7、Fiber optic sensors.

Detailed Images

Various Choice to Meet Your Different Needs

1.Custom Connector & Polish Type
