Model No.: GYXTW
Brand: OEM
Place Of Origin: China
Number Of Cores: ≥ 10
Application: Aerial/Duct
Out Sheath: HDPE/LSZH Sheath/flame Retardant Sheath/anti-roden
Fiber Type: G652D/G657A1/G657A2,OM3,OM4
Fiber Counts: 2~288 cores
OEM: YES
Allowable Tensile Strength: 600/1500N
Packing: 1~6km per spool
Armored: Steel Tape,Steel Wires
Diameter: 8.0mm
Certification: ISO9001
| Selling Units: | Kilometer |
| Package Type: | wooden spool |
| Picture Example: |
|
The file is encrypted. Please fill in the following information to continue accessing it
|
| G.652 | G.655 | 50/125μm | 62.5/125μm | |
| Attenuation | @850nm |
|
| ≤3.0dB/km | ≤3.0dB/km |
| @1300nm |
|
| ≤1.0dB/km | ≤1.0dB/km | |
| @1310nm | ≤0.36dB/km | -- |
|
| |
| @1550nm | ≤0.22dB/km | ≤0.23dB/km |
|
| |
| Bandwidth (Class A) | @850 |
|
| ≥500MHZ·km | ≥500MHZ·km |
| @1300 |
|
| ≥1000MHZ·km | ≥600MHZ·km | |
| Numerical Aperture |
|
|
| 0.200±0.015NA | 0.275±0.015NA |
|
Cable Cut-off Wavelength λcc | ≤1260nm | ≤1480nm |
| ||
| | | | |
| |
|
| GYXTW-2～12 | 2～12 | 9.0 | 85 | 600/1000 | 500/1500 | 15D/30D |
| GYXTW-14～24 | 14～24 | 9.0 | 85 | 600/3000 | 1000/3000 | 15D/30D |
| GYXTW-2～12 | 2～12 | 10.0 | 105 | 1000/3000 | 1000/3000 | 15D/30D |
| GYXTW-14～24 | 14～24 | 10.0 | 105 | 1000/3000 | 1000/3000 | 15D/30D |
| GYXTW-26～36 | 26～36 | 14.0 | 190 | 1000/3000 | 1000/3000 | 15D/30D |
| GYXTW-38～48 | 38～48 | 15.0 | 216 | 1000/3000 | 1000/3000 | 15D/30D |
Storage/Operating Temperature : -40℃ to + 70℃
Packaging: wooden spool
Productivity: 15000 Kilometer per Month
Transportation: Ocean,Land,Air,Express
Place of Origin: China
Supply Ability: 15000 Kilometer per Month
Certificate: CE/ROHS/ISO9001 /ANATEL
HS Code: 8544700000
Port: Shenzhen,Guangzhou
Payment Type: L/C,T/T,Paypal,others,Cash
Incoterm: FOB,CFR,CIF,EXW,FAS,FCA,CPT,CIP,DDP
